Double Injection MoldA parison for blow molding is applied to a core rod by successive injectionoperations in different injection molds. The material for the first layer is injected into the end of the mold cavity remote from the neck portion of the core rod, in the usual manner. The second layer is injected into the second injection moldcavity adjacent to the neck of the core rod to flow over the first layer in a direction from the cooler part of the first layer toward the hotter part. The twolayer parison is th |
| High Light: | injection mold machines,injection molding equipment |
||
|---|---|---|---|
600Ton Variable Pump Injection Molding Machine with Double oil tank
Selling points
SPECIFICATIONS
| SPECIFICATIONS | ||||
| DESCRIPTION | UNIT | K2-650 | ||
| INJECTION | A | B | C | |
| SHOT VOLUME | CM3 | 2160 | 2734 | 3376 |
| SHOT WEIGHT | G | 1966 | 2488 | 3072 |
| (PS) | OZ | 68.8 | 87.1 | 107.5 |
| SCREW DIAMETER | MM | 80 | 90 | 100 |
| INJECTION PRESSURE | MPA | 215 | 170 | 138 |
| SCREW L:D RATIO | 21:1 | 21:1 | 19:1 | |
| SCREW STROKE | MM | 430 | ||
| SCREW SPEED (STEPLESS) | R/MIN | 0~125 | ||
| CLAMPING UNIT | ||||
| CLAMPING FORCE | KN | 6500 | ||
| OPENING STROKE | MM | 920 | ||
| PLATEN SIZE | MM*MM | 1320*1290 | ||
| SPACE BETWEEN TIE BARS | MM*MM | 930*900 | ||
| MOLD THICKNESS (MIN-MAX) | MM | 350~910 | ||
| MAX.DAYLIGHT | MM | 1830 | ||
| HYDRAULIC EJECTION STROKE | MM | 265 | ||
| HYDRAULIC EJECTION FORCE | KN | 182 | ||
| POWER UNIT | ||||
| HYDRAULIC SYSTEM PRESSURE | MPA | 17.5 | ||
| PUMP MOTOR(V/S) | KW | 55/2*28.3 | ||
| HEATING CAPACITY | KW | 38.3 | ||
| NUMBER OF TEMP CONTROL ZONES | 6+NOZZLE ) | |||
| GENERAL | ||||
| DRY-CYCLE TIME | SEC | 6 | ||
| OIL TANK CAPACITY | L | 1500 | ||
| MACHINE DIMENSIONS | MXMXM | 9.6*1.9*2.3 | ||
| MACHINE WEIGHT | KG | 36000 | ||
Feature:
CONTROL PART
It adopts imported plastic injection computer ,with large screen high definition crystal display and human - computer interface in both Chinese and English.through CPU independent control and treatment , it have raised the running speed of the control system and alarming of ultra-high oil temperature ,thus improving the operating speed of the machine .
It uses closed -loop temperature control system to ensure the accuracy and the reliability of the barrel temperature ,it is also equipped with the functions of cold -proof start ,alarming and parameter memory for the modeling ,with password protection ,The injection and switch are controlled by imported location ruler .
INJECTION PART
The excellent chrome ,molybdenum and aluminum alloy screw and barrel have undergone the nitriding process ,applicable tovarious plastic materials .
The injection cylinder is parallel or balance to both sides of the barrel ,so as to ensure the non de-viation of the nozzle ,good sealing and nonleak-age of rubber ,it is equipped with double guide pillar supporting system ,which can inject under multi-pressure and at various speeds .it also uses one -stop hydraulic motor pre -injection device
HYDRAULIC PART
It adopts the imported top quality hydraulic components and the cart ridge valve.
MOLD PART
Oil motor drives the adjustment of gear mold ,with good synchr-ocyclotron . The die can be adjusted automatically in accordance with the set pressure ,which is both convenient and reliable .
Five- support crankshaft stucture .The mold and the supports all use the portal structure ,with good rigidity and high fitting precision,Adopting the computer optimized design ,the mold employs definite analysis less system ,With doublecore pulling device ,it boasts super sensitive low pressure protection functions. The mechanical ,hydraulic and electrical protections have ensured the human safety ,The dismountable fill-out hopper can be installed conveniently and automatically ,The moveabel platen is running in roll,with little friction and balanced and dependable moving
