Plastic Injection MoldSolder mask is exposed to the pads used, it is often said that the green oil, oil is actually digging holes in the green, the green oil does not need to cover the pads and other exposed areas. Proper cleaning can get a suitable surface features. HASL solder coating HAL (commonly known as HAL) process is first dipped on the PCB flux, then dipping in molten solder, and then |
Skype: df mold
Specification: |
|
Certificates |
AAA grade credit enterprise, ISO9001, ISO14001, SGS |
Quality-guaranteed |
Japanese standard of QC management & Euramerican standards |
Service |
Designing the mould, CNC processing and other tooling, assemble all mould parts |
OEM & ODM service |
Acceptable |
Design software |
UG, PRO-E, CAD, CAXA, etc |
Mould base Standard |
LKM , HASCO , DME, etc |
Moulds’ steel |
NAK80, S136(H), 2738, 718&738 and P20 etc |
hardness of steel: |
15--60 HRC |
cav/core material |
2738,2343,DIN-1,S130,2344,738H,718,8407,S136,NAK80,P20 etc |
Cavity |
Single/multi |
Runner |
Hot/cold |
Mould life |
500,000-1,000,000 shots as you required |
Final products’ materials |
ABS, PP, PE, POM, PA6(66)+GF, PC, PMMA HIPS, GPPS etc |
Final Products’ colors |
Any color as your required |
Lead Time |
25-50 workdays based on the different products |
Relevant requirements reachable |
ROHS, UL, or as requested |
Package |
Wooden case package or follow customers' requirement |
Price Terms |
FOB Shanghai Port, China |
Payment term |
T/T, L/C at sight |
