380Tons PET Bottle Preform Making Machine HCW380PET
| Condition: |
New
|
Type: |
Preform Injection
|
Style: |
Horizontal
|
| Brand Name: |
HAICHEN
|
Model Number: |
HCW380PET
|
Place of Origin: |
Zhejiang, China (Mainland)
|
| Plastic Type: |
Thermoplastic
|
Automatic: |
Yes
|
Injection Weight: |
2040g
|
| Clamping Force: |
3800KN
|
Opening Stroke: |
705 mm
|
Power(W): |
37 KW
|
Applications:
Available mold cavities on HCW380 PET Preform Injection Molding Machine:
For PET perform 15g-20g, 15mm-20mm, mold cavity can be: 8-Cavities, 12-Cavities, 16-Cavities, 24-Cavities, 32-Cavities,
For PET perform 16g-48g, 28mm PCO, 25mm/30mm, mold cavity can be: 8-Cavities, 16-Cavities, 24-Cavities, 32-Cavities,
For PET perform 50g-500g, 60mm-120mm, mold cavity can be: 2-Cavities, 4-Cavities, 6-Cavities, 8-Cavities, 12-Cavities,
Quick Detail:
Machine main components adopt world famous brand, e.g.:
• PLC: TECHMATION CONTROLLER(Taiwan)
• AC Contactor: SIEMENS(Germany)
• Travel switch: SCHNEIDER(FRANCE),
• Transducer: NOVOTK (Germany)
• Proportional Valve: HNC(TAIWAN)
• Oil pump: VICKERS(USA)
• Directional Valve: VICKERS(USA)
• High-pressure pipe line: GOOD YEAR (USA)
Description:
HCW380 PET Preform Injection Molding Machine adopted special prolonged screw, which is the type of fully-automatic machine, being provided with high efficiency, high reliability, high speed, low noise, low power consumption and other advantages.
Competitive advantages:
1. This machine adopt special PET screw, prolonged screw and barrel will ensure PET plasticizing effect, to make performs with good brightness and transparence, the production is with low defect.
2. Increased oil pump’s power
3. Increased heating ring’s power
4. Linear slide rail
5. Large capacity
6. hydraulic system
Specification:
| INTERNATIONAL CLASS NO |
HCW380PET |
| |
|
B |
C |
| INJECTION UNIT |
|
|
|
| Screw diameter |
mm |
75 |
80 |
| Screw L/D ratio |
L/D |
24 |
24 |
| Shot volume(theoretical) |
cm3 |
1650 |
1880 |
| Injiection weight(PET) |
g |
1790 |
2040 |
| Injection rate |
g/s |
470 |
538 |
| Injection pressure |
Mpa |
173 |
152 |
| CLANPING UNIT |
|
|
| Clamping force |
kN |
3800 |
| Open stroke |
mm |
705 |
| Space between tie bars(W×H) |
mm |
730*710 |
| Max.Mold height |
mm |
750 |
| Min.Mold height |
mm |
250 |
| Ejector stroke |
mm |
180 |
| Ejector force |
kN |
70 |
| OTHERS |
|
|
| Max.Pump pressure |
MPa |
16 |
| Pump motor power |
kW |
37 |
| Heating power |
kW |
46 |
50 |
| Machine dimension(L×W×H) |
m |
7.5*1.9*2.0 |
| Oiltank cubage |
L |
630 |
| Machine weight |
t |
15.4 |
